ไทยNetnode IP MESH Phase 4 – Robust 2 W
NETNode IP radios can be combined in a fluid self-forming, self-healing mesh containing up to sixteen radios. The NETNode radios within the mesh exchange data on a single frequency, simplifying frequency management. The entire mesh occupies just 2.5MHz of bandwidth (3.0, 3.5, 5.0, 6.0 and 8.0MHz also available). The NETNode radios employ the unique DTC COFDM modulation scheme and therefore offer excellent RF penetration and performance in the presence of multipath.
The NETNode mesh radios can provide up to 8.8Mb/s of IP data (data rate depends on mode, number of nodes and range between nodes). This available bit-rate can be used to exchange IP data traffic between nodes.
The NETNode can be connected to third party composite cameras using the AVI option and PTZ control can be achieved using the serial interface.
- 2W transmit power
- COFDM waveform for excellent NLOS & multipath performance
- Flexible RF channel bandwidths (2.5,3,5,6 MHz)
- Range of frequency variants across public and private bands
- Up to 8.8Mbps UDP data capacity in a Mesh
- Up to 16 nodes in Mesh
- Optional AVI upgrade for composite camera input
- Built in encryption (DES as standard, AES128/256 available subject to Export Control)
